Villa Eaves Lines Sunshade Aluminum Panels Waterproof Moisture Proof

Outdoor canopy, villa eaves lines, sunshade special aluminum plate, typhoon insulation, waterproof, moisture-proof.

PRODUCT DESCRIPTION

1. Performance advantages
- Weather resistance: -40°C~80°C without cracking and pulverization, passed the 3000 hours salt spray test.
- Self-cleaning: low surface energy, can be cleaned by rain, reducing maintenance costs.

2. Substrate requirements

- Made of high-quality 3003/5005 aluminum alloy, the thickness is strictly controlled at 2.5±0.1mm to ensure strength and flatness.
- Plates need to be degreased and chromed to enhance surface adhesion and corrosion resistance.

3. Surface effect
- Optional matte/metallic gloss, color support RAL/Pantone color card customization, color difference ΔE≤1.0.
- Additional imitation stone/wood grain transfer process to meet high-end decoration needs.

4. Fluorocarbon coating process

- Three coats and two bakes (primer, topcoat, varnish) with a total coating thickness of ≥ 40μm in accordance with AAMA 2605*.
- PVDF fluorocarbon resin accounts for ≥70%, and has UV resistance and weather resistance for more than 20 years.

5. Installation adaptability
- Pre-installed stiffeners and buckle grooves, suitable for dry hanging system, wind pressure resistance ≥ 9kPa (12 wind levels).

Quick Details:

1.Made-to-order style:Flat, perforated, hollowed, hyperbolic and double-arc, spherical, artistic modeling.

2.Surface treatment:PVDF/PPG/Imitation Wood Grain or Customized.

3.Customizable thicknesses are available:1.5mm 2.0mm 2.5mm 3.0mm

4.Design style:Modern minimalist, retro nostalgic.

Usage

1. Curtain wall decoration: fluorocarbon-coated aluminum panels create a modern façade and enhance the visual grade of the hotel;
2. Roof modeling: lightweight characteristics to achieve complex curved surface design and enhance architectural artistry;
3. Canopy logo: Customized etched LOGO combined with lighting to strengthen brand recognition;
4. Indoor partition: imitation wood grain transfer aluminum plate creates a warm atmosphere and takes into account fire prevention needs;
5. Elevator edging: 3mm thickened aluminum plate is anti-collision and wear-resistant, maintaining the aesthetics of high-frequency use;
6. Energy-saving enclosure: The hollow insulation structure reduces the energy consumption of air conditioners and meets green building standards.

Features

1. High weather resistance: PVDF fluorocarbon coating, UV resistance, acid and alkali resistance, 20 years of non-fading powdering, adaptable to extreme climates.
2. Lightweight and high strength: 2.5mm thick aluminum alloy substrate, light weight (about 7kg/㎡) but wind pressure resistance up to 9kPa, high safety.
3. Fire safety: A2 grade non-combustible material, in line with building fire protection codes, to ensure the public safety of the hotel.
4. Customized appearance: Support imitation stone, wood grain and other transfer processes, and the color (RAL color card) accurately matches the hotel design style.
5. Convenient installation: pre-installed stiffeners and buckle grooves, adapted to the dry hanging system, high construction efficiency and good flatness.
6. Environmental protection and energy saving: The high reflectivity of the surface reduces heat absorption and reduces air conditioning energy consumption, meeting green building standards.
